| Keihan 7000 series | |
|---|---|
 Set 7002 in January 2021 | |
| In service | 1989– |
| Manufacturer | Kawasaki Heavy Industries |
| Family name | City commuter |
| Constructed | 1989–1993 |
| Entered service | 1989 |
| Refurbished | 2006–2008 |
| Number built | 28 vehicles (4 sets) |
| Number in service | 28 vehicles |
| Formation | 7 cars per trainset |
| Fleet numbers | 7001–7004 |
| Capacity |
|
| Operators | Keihan Electric Railway |
| Lines served | Keihan Main Line |
| Specifications | |
| Car body construction | Aluminium |
| Train length | 130,900 mm (429 ft 6 in) |
| Car length | 18,700 mm (61 ft 4 in) |
| Width | 2,780 mm (9 ft 1 in) |
| Height | 4,185 mm (13 ft 8.8 in) |
| Doors | 3 pairs per side |
| Maximum speed | 110 km/h (68.4 mph) (service) 120 km/h (74.6 mph) (design) |
| Traction system | Variable frequency (GTO) |
| Power output | 4× 200 kW (268 hp) |
| Acceleration | 2.8 km/(h⋅s) (1.7 mph/s) |
| Deceleration | 4 km/(h⋅s) (2.5 mph/s) (operation) 4.5 km/(h⋅s) (2.8 mph/s) (emergency) |
| Electric system(s) | 1,500 V DC |
| Current collector(s) | Overhead wire |
| Safety system(s) | Keihan ATS |
| Track gauge | 1,435 mm (4 ft 8+1⁄2 in) |
The Keihan 7000 series (京阪7000系, Keihan 7000-kei) is an electric multiple unit (EMU) commuter train type operated by the private railway operator Keihan Electric Railway in Kyoto, Japan, since 1989.[1]
Overview
The 7000 series was introduced in 1989 with two six-car sets and one four-car set. The remaining nine cars would be built between 1991 and 1993.[2]
In 1993, three test 6000 series vehicles would be renumbered and incorporated into a fourth seven-car set.[2]
These trains would be the basis for the 7000 series introduced in 1992.[3]
Interior
Passenger accommodation consists of longitudinal bench seating throughout.
Formations
The seven-car trains are formed as follows, with two or three motored ("M") cars and four or five non-powered trailer ("T") cars.[4]
| Designation | Mc | T | Mc | ||||
|---|---|---|---|---|---|---|---|
| Numbering | 7000 | 7500 | 7600 | 7150 | 7650 | 7550 | 7050 |
| Designation | Mc | T | Mc | ||||
| Numbering | 7000 | 7500 | 7100 | 7600 | 7550 | 7650 | 7050 |
- "Mc" cars are motored driving cars (with driving cabs).
- "M" cars are motored intermediate cars.
- "T" cars are unpowered trailer cars.
- The "Mc" and "M" cars each have one scissors-type pantograph along with the "7150" car.
Gallery
Inside a 7000 series train
Cabin of car 7001
Keihan 7053 in an older green livery
Set 7002 campaigning for Thomas & Friends in 2008
Keihan 7054 on a service to Yodoyabashi
References
- ↑ "7000系" [7000 Series]. Keihan.co.jp (in Japanese). Retrieved 30 January 2020.
- 1 2 "京阪電気鉄道 現有車両プロフィール 2009" [Keihan Electric Railway Current Vehicle Profile 2009]. The Railway Pictorial (in Japanese). Denkisha Kenkyukai. 822: 256–258. 2009.
- ↑ 私鉄車両年鑑 2013: 大手15社営業用車両完全網羅 私鉄車両年鑑2013 [Japan Private Railways Annual 2013] (in Japanese). Tokyo, Japan: Ikaros Publications Ltd. 20 March 2013. p. 79. ISBN 978-4-86320-693-9.
- ↑ 私鉄車両編成表 2009 [Private Railway Vehicle Organization Table 2009] (in Japanese). Japan: Kotsu Shimbunsha. 2009. p. 120. ISBN 978-4330082097.
